THE BRIGHTEST DISPLAY AND THE HIGHEST PERFORMACE TABLET ON THE MARKET

Overview

Recommended items for RC mounting:

Adjustable arm

Adapter

8 Inch 1300 nits Sustained Brightness

4K Ready Display

4G LTE Unlocked Smartphone

12GB RAM / 256 GB Storage

4K-48MP Camera

Hyper-Engine 8 Core CPU (70% faster than T8)

12,200 mAh Large Battery

WIFI 2,4/5 GHz

Bluetooth 5.0

NFC

GPS Built-in

SD card slot up to 2 TB

Waterproof IP68

Military Standard construction

HDMI Output Port

USB Type C 3.0

External power pin port IP68

Ultra Fast Charging at 36W.

More Info

For in-the-field Professionals

Designed for professionals who require a reliable companion that performs flawlessly in any weather conditions.

The most powerful processing capabilities of any rugged tablet on the market, together with unparalleled battery life

and ultra-rugged design IP68 rated.

It operates seamlessly rain or shine to match your work ethic.

Durability

Built using high strength polyurethane and aluminum alloy.

Protected from accidental drops.

Supports up to a ton of pressure

Dust and Water-Resistant submerged up to 4 feet for 30 minutes. IP-68 Certificated

Can withstand extreme temperature ranges ranging from -4°F to 124°F.

Keeps your device fully operational through a battery that holds its charge for up to 30 days on standby.

The Fast Charging capability at 36W, takes less than 3 hours to fully charge from 1%.

Display

Ultra-Bright 1300 cd/m² SUSTAINED BRIGHTNESS

The brightest tablet/smartphone on the market, over three times brighter than other mobile devices

Operate your display under direct sunlight, no dims

4K Ready High-Resolution Display.

High Color accuracy and wide Gamut.

Polarized screen for operation with polarized glasses.

Glove touch and Wet touch.

4K Camera

The back Camera now allows recording in 4K

Take pictures at 48 Megapixels.

Front Camera records at 1080p and captures images at 20 Megapixels.

Connectivity

4G LTE Smartphone, Cellular service calls, and Data

Full-size HDMI Output Port

HDMI Input compatible through USBc

Protocol to reduce the power draw from drone controllers

The most LTE Bands equipped out of any other Tablet.

USBc 3.0 port with speed up to 20GB/s.

Highly accurate, real-time positioning internal GPS

WIFI 5 Dual-brand (2.4GHz/5Ghz)

Weather-proof external charging pin port

Bluetooth 5.0

NFC connectivity

HDMI Port

The new HDMI port empowers you to mirror the screen on any monitor or device equipped with a HDMI port.

Specifications

PROCESSOR

Hyper-engine Octa-Core 64 bits chip
3D 4K Ready GPU
Ai Accelerator

MEMORY

12 GB RAM

STORAGE

256GB Internal Storage
Media slot up to Micro 2TB SD card

DISPLAY

Active viewing area: 8-inch(diagonal)
True sunlight-readable 1300 nits Sustained Brightness, no dims.
4K Ready Display for 4K content
2560x1600 pixel resolution
Fully laminated display
Capacitive multitouch for use with gloves and wet conditions
Antireflective UV coating
Oleophobic coating, fingerprint resistant
Polarized filter compatible with polarized
Glasses

CELLULAR CAPABILITIES

4G LTE Unlocked
Data and voice capable with earpiece integrated
FDD-LTE BANDS
B1/2/3/4/5/7/8/12/13/14/17/18/19 20/25/26/28/66/71
TD-LTE BANDS
B 38/39/40/41
All required bands for compatibility with Verizon, AT&T, and T-Mobile in the USA
Compatible with all carriers in the World
Nano SIM card (2 slots)
PTCRB Certified for all carriers
GCF Certified for all carriers

OPERATING SYSTEM

Android Google 12 Certified
Google Stock version no bloatware

CAMERAS

Back Camera:
48 Megapixel 27mm equivalent focal length
Capable 4K Video recorder up to 48MP @ 30fps

Front camera:
20 Megapixel Front camera
Capable 1080p

PORTS

USB Type C 3.0 with flap cover
Data transmission up to 5Gb per second
Power delivery capable
Fast Charging
HDMI Output with flap cover
HDMI Input through the USBc (adapter required)

BATTERY

Lightweight 12,200 mAh Li-Ion battery
Operates 10 hours on one charge on maximum brightness
Operates 72 hours on one charge on AutoBrightness
15 days on Standby duration
Optimized for strong performance in cold and hot temperatures
Fast charging at 36W in 3.5 hours

NAVIGATION OFFLINE

High Precision , ultra-fast GPS with 1-meter accuracy
Compatible GPS+, Glonass, BeiDou, Galileo
Digital 3D Compass

WIRELESS CAPABILITIES

Long-range Bluetooth® Smart Ready wireless technology, v5.0 + EDR
Wi-Fi 802.11 a/b/g/n/ac, 2.4 GHz and 5 GHz
NFC Transmission capable

LANGUAGE

English, Spanish, Portuguese, Italian, German, Japanese,
Dutch, French, Polish, Romanian, Turkish, Russian, Arabic,
Indonesian, Malay, Thai, Vietnamese, Hindi, Hebrew, Chinese, etc.
All Google Android Languages available

RUGGED FEATURES

Waterproof IP68 closed flaps 2 meters for 4 hours.
Dustproof IP68 closed flaps
Dropproof /IK: multiple drops from 4′ (1.2 –1.5 m) onto flat surface concrete
Shake-proof: 1-19Hz/1.0mm; 19-200Hz/1.0g Storage temperature: -20°F to 170°F (-28°C to 76°C)
Operating Temperature: -4°F to 124°F (-20°C to 51°C)
Certification: Military Standard 810G
Method 500.5 Low Pressure (Altitude); Method 501.5 High Temperature; Method 502.5 Low Temperature;
Method 503.5 Temperature Shock; Method 506.5 Rain; Method 507.5 Humidity; Method 510.5
Sand and Dust; Method 512.5 Immersion; Method 514.6 Vibration; Method 516.6 Shock

SENSORS

Direction Sensor
Gravity sensor
Magnetic Field Sensor
Motion sensor
Rotation Vector
Ambient Light sensor
Accelerometer sensor
Compass

PHYSICAL

Size:8.75(22cm) x 5.25(13cm) x 0.6(1.5cm) Inches （L×W×H）
Weight: 1.3 pounds / 590 grams
Durable, chemical- and shock-resistant design
Easy-to-grip,
Impact-absorbing over-molded bumpers
Lightweight and ergonomic design
Construction: Thermoplastic polyurethane injection and aluminum

Compare Models

	TRIPLTEK MINI	TRIPLTEK 9 PRO
Screen Size	6.1 inches	8 inches
Display Brightness	1300 nits sustained	1300 nits sustained
Display Resolution	2160 by 1080 pixels	4K Ready
Memory RAM	6 GB	12 GB
Memory Storage	128 GB storage	256 GB storage
Smartphone call function	4G LTE unlocked 22 LTE Bands	4G LTE unlocked and Earpiece 23 LTE Bands
Ports	USB Type C 2.0	HDMI Port, USB Type C 3.0 External Charging port IP68
Waterproof Protection	Splash protection	Waterproof Dustproof IP68
Processor	Hyper-engine 50% faster thanT8 3D GPU 3x times faster than T8	Hyper-engine 70% faster than T8 3D 4K GPU 3x times faster than T8
Battery size	5,000 mAh battery	12,200 mAh battery Fast Charging 36W
Rear Camera	n/a	48 Megapixel- 4K
Front Camera	21 Megapixel	20 Megapixel
Sound	Stereo speaker	Stereo speaker
Android version	Android 12	Android 12
SD card maximum size	SD card up to 2TB	SD card up to 2TB
Networking	WIFI Dual band 2.4/5Ghz Cast to wireless display GPS+, Glonass, Galileo, Beidou Compass Bluetooth 5 NFC	WIFI 5 bands 2.4/5Ghz Cast to wireless display GPS+, Glonass, Galileo, Beidou Digital Compass Bluetooth 5 NFC
Construction	Aluminum and composite	Military Standard 810G
Weight	7.2 oz (204 gram)	1.3 pounds (590 gram)
Size	6.25x3x0.40 inches(LxHxW)	8.75x5.35x0.60 inches(LxHxW)
